Valo Grand Black
1 x VALO Grand LED curing light
4 x Rechargeable batteries
1 x Battery charger
1 x Charging unit power supply
1 x Handpiece bracket holder
1 x VALO Grand Light Shield
50 x Barrier sleeves
Designed for durability, accessibility and power
The VALO Grand Black curing light has the same accessibility, durability, and power as the original VALO curing light and all the freedom of VALO Cordless light, plus the added benefit of a 50% bigger lens. The 12 mm lens is designed to easily cover a 10 mm molar for quick and effective curing. The larger footprint that makes it even easier to cure a large surface area quickly and effectively. The VALO Grand light also features a second activation button on the underside of the unit for more intuitive operation.
The VALO Grand light uses a custom, multiwavelength light-emitting diode (LED) for producing high-intensity light at 395-480 nm capable of polymerising all light-cured dental materials. This intensity will also penetrate porcelain and is capable of curing underlying resin cements similar to a quality halogen light.
The unibody construction ensures durability and provides unsurpassed heat dissipation. The elegant, ergonomic, and streamlined design enables the VALO Grand light to easily reach all curing sites without sacrificing patient comfort. The aluminium wand, machined components, and tempered glass lens make it the most durable cordless curing light available.
The VALO Grand curing light operates on two lithium iron phosphate batteries that deliver the consistent high-energy power the VALO light requires. These batteries are also inexpensive, rechargeable, and widely available.
Every VALO starts as a solid bar of tempered, high-grade, aerospace aluminium, which is CNC precision milled. True unibody construction ensures VALO’s durability and provides unsurpassed heat dissipation. With its aluminum wand, machined components, and tempered glass lens, VALO is the most durable curing light available.
VALO’s wand-style body and lens system eliminates the need for a light guide, allowing direct access to all areas of the mouth without overstretching a patient’s TMJ and soft tissues, a common problem that can occur with other lights. The elegant, ergonomic, and streamlined design enables VALO to easily reach all curing sites, delivering energy directly without sacrificing patient comfort.
With 3 curing options – standard power, high power and new plasma emulation mode with all unique timing intervals enables the practitioner to choose the right power for any given procedure. Valo cures all restorations due to combined dyes creating wavelengths of light that cure all lightcured dental materials with the touch of a button. VALO features a slender,aerospace aluminium body, making it lightweight and exceptionally durable.
VALO uses a custom, multiwavelength LED for producing a high-intesity light at 395-480nm. This broad-spectrum light output means VALO is capable of polymerising all light-cured dental materials-including those with camphorquinone and the entire range of proprietary photoinitiators. In addition, VALO’s large 9.6mm footprint and optimally collimated beam delivers consistent, uniform power over a range of surfaces and working distances. Other curing lights’ beams dissipate even at distances as short as 4mm, which results in significant energy loss to the curing site. The intensity and consistency of VALO’s collimated beam, combined with the proprietary LED pack and broad-spectrum output, deliver the energy needed to completely polymerise any resin – even at distances as far as 10mm from the restoration site.
Read The VALO Story on our blog.
View the full range of Ultradent Products
To read more and find helpful tips visit Ultradent Blogs
– Collimated beam delivers a complete uniform cure
– Broadband LED’s cure all dental materials
– Three curing options – standard, high power and plasma emulation
– Slender, aerospace aluminium body
– Lightweight and exceptionally durable
– 50% bigger lens
Hints & Tips
How concentrated does the light become with the PointCure lens attached?
The light is focused to a 2.5mm aperture, which makes it ideal for tacking veneers and all-porcelain crowns.
How long do veneers and crowns need to be tack cured with the PointCure lens?
For veneers, a 1-second tack cure with VALO light on high power mode is all you need. For all-porcelain crowns, a 2-second cure with VALO light on high power mode from the occlusal surface is sufficient in most cases.
Can TransLume lenses be used for curing?
How should the various lenses be cleaned?
Cold disinfect the lenses using any surface disinfectant. Do not use an ultrasonic to clean the lenses. Do not autoclave.
My VALO Cordless light doesnt fit in the wall mount I received. What do I do?
The wall mount will fit both the VALO and VALO Cordless lights. Because the VALO Cordless light has a larger wand body, it needs to be stored upside down in the wall bracket.
How do the lenses attach to the VALO curing light?
Each lens is magnetically attached to the head of the light. The magnet is strong enough for a secure attachment, but still allows for easy detachment at the right time.
